Gesture Controlled Decade Counter with 4026 IC and circuit diagram


This IC needs 5v power supply, a clock button(LDR),a reset button. In this video the practical operations are shown. The circuit is described in the picture.Happy Circuiting! (At the sw1 the LDR was used. If we are using an LDR then we must use Rclk=100K ohm.)
